CMM is one of China manufacturers & suppliers who mainly produces G10 Portable Handheld Pneumatic Crusher with many years of experience. Hope to build business relationship with you.
As Follows:
Model |
G10 Portable Handheld Pneumatic Crusher |
Certification |
MA KA |
Certification NO. |
MED |
Dimension |
575×170×90mm |
Weight |
10.6 Kg |
Cylinder diameter |
38mm |
Piston stroke |
155mm |
Piston weight |
0.9Kg |
Impact energy |
≥43(0.63Mpa)≥39.3(0.5Mpa) ≥32(0.4Mpa)J |
Impact frequency |
≥16.5(0.63Mpa)≥16.5(0.5Mpa) ≥15(0.4Mpa)Hz |
Air consumption |
≤26(0.63Mpa)≤20(0.5Mpa) ≤16(0.4Mpa)L/s |
Shank dimension |
24mmX70mm |
Air hose I.D |
16mm |
